Lemon Vegetable And Fruit Freeze Dryer

If the lemon vegetable and fruit freeze dryer caters to your requirement, welcome to buy the precise equipment made in China from our factory. We are one of the professional manufacturers and suppliers in China who can offer you unmatched services and prices. And the customized service is also available. Don't hesitate any more.



Lemon Vegetable And Fruit Freeze Dryer

Freeze-dried lemons are very valuable products for anti-cancer. Fruit and vegetable freeze-drying machine production line, freeze-drying process: fresh fruit and vegetable raw materials → pre-treatment (peeling, cleaning, slicing) → pre-freezing → quick-freezing → drying (sublimation drying - analytical drying) → post-processing.

The products processed by the lemon vegetable and fruit freeze dryer have no astringency and no bitter taste (lemon seeds contain limonin, which is a very valuable product for anti-cancer. The lack of bitterness here does not mean that the lemon itself has a bitter taste that is not formed by processing. .) Same as the taste of Xinguo, I personally feel that freeze-dried lemon slices are better than Xinguo, without the sourness of ordinary slices, and it tastes the same without any sweet condiments such as honey. Freeze-dried food is generally used for In spaceflight work, not only the unique color, aroma, taste, shape and various biologically active nutrients of lemon fresh fruit are maintained, but the aroma is exactly the same as that of freshly cut fresh fruit. Rich in vitamins, limonin, and other nutrients that the human body needs. Excellent rehydration, without any additives, it is a good product for tea drinking and cooking seasoning. The price is certainly more expensive than the dark roasted lemon slices sold in the supermarket. Rich in Vc, Vp, Ve, Vk, Va, Vb, inositol, citric acid, amino acids, proteins, minerals and other 17 kinds of vitamins and trace elements that the human body needs.

The composition system of fruit and vegetable freeze dryer:

1. Control system: It consists of a programmable program controller, touch screen, peripheral relays, sensors, etc.

2. Refrigeration system: It consists of refrigeration compressors and auxiliary facilities to provide cold sources for drying boxes and cold traps. (In the refrigeration system, in addition to the displayed high and low pressure pressure gauges, a pressure controller is also installed. When the high pressure is too high, the high pressure relay will act, and the compressor will stop working)

3. Circulation system: Freeze drying and heating are a process technology that relies on temperature difference to cause material transfer. The cooling and heating of the shelf are carried out by the heat transfer of the heat transfer oil. In order to make the heat transfer oil continuously circulate in the whole system, we add a shielded circulating pump to the pipeline.

4. Vacuum system: It consists of drying box, cold trap, vacuum valve, vacuum pump, vacuum pipeline, vacuum measurement regulation and other parts. The vacuum pump group has a strong suction capacity, on the one hand, it promotes the sublimation of the moisture in the drying box under vacuum, and on the other hand, the system forms a vacuum pressure difference between the cold trap and the drying box, so that the moisture in the drying box is sublimated and cooled. trap capture.

5. Hydraulic system: It is mainly used to press the cork into the bottle mouth at the end of drying.

Parameter：

Model	KFD-20	KFD-25	KFD-30	KFD-40	KFD-50	KFD-100	KFD-150	KFD-200
Capacity (Kg/Batch)	200	250	300	400	500	1000	1500	2000
Shelf Area (㎡)	20	25	400	40	52	102	152	201
Shelf Size (Mm)	2200*600	2200*600	3300*600	3300*600	3300*600	5000*600	10000*600	9900*600
Shelf Quantity (Layer)	8+1	10+1	8+1	10+1	13+1	17+1	13+1	17+1
Shelf Quantity (Piece)	18	22	18	18	28	36	28	36
Space Between（Mm）	95
Shelf Temperature (℃)	room to 120
Water Catcher Temper (℃)	-65±5
Max Catch Water（Kg）	300	380	450	600	750	1500	2200	3000
Ultimate Vacuum （Pa）	5
Electricity（kW）	63	72	101	116	168	232	287	384

Pre-sale:

* As soon as we get your inquiry, we will always reply to your email on time and try our best to recommend you the most suitable freeze dryer. Detailed tech info will also be provided for you.

* We can do sample tests for customers.

After-sale:

* If possible, please do come to our factory and we will teach workers the whole process of freeze-drying. The most appropriate time needed for freeze-drying will be tested by us.

* We will keep in touch with you, to make sure every part of the freeze dryer works well. One-year warranty, free online service for abroad customers.
