Corn Pulp Freeze Dryer
Size: from 0.5 to 200m²
Highlight: can be customized
Warranty:one year
Corn Pulp Freeze Dryer
Tender corn pulp is a traditional food of the Tujia nationality. Because it is obtained by grinding corn into pulp, its products are easy to ferment and deteriorate. If the traditional heating and drying method can not retain its fresh flavor, frozen storage is also easy to deteriorate and inconvenient to eat. The application of food lyophilizer in brewing corn juice lyophilized powder can dehydrate the corn pulp, fully remove the water in the corn pulp, retain the fresh flavor and nutritional components of the corn pulp, and is convenient to eat. When eating, add a little water, stir evenly, and then it will be the original corn slurry. Fry it into corn cake or cook it into corn porridge.
In the freeze-drying processing method of brewing corn juice freeze-dried powder, the food freeze-drying machine threshes the corn into corn kernels, cleans and removes sundries, grinds it into slurry, and then sends it to the freeze-drying machine for low-temperature freeze-drying and dehydration. In the freeze-drying process, it is frozen to minus 30 ℃ in the pre-freezing stage, and the temperature of corn slurry is controlled at - 20 ℃ - 50 ℃ in the drying stage until the corn juice freeze-dried powder is dehydrated to less than 5%, Then seal the package.
Parameter：
Model | KFD-1 | KFD-2 | KFD-5 | KFD-6 | KFD-8 | KFD-10 |
Capacity (Kg/Batch) | 10 | 20 | 50 | 60 | 80 | 100 |
Shelf Area (㎡) | 1.1 | 2 | 5 | 6 | 8 | 10 |
Shelf Size (Mm) | 500*400 | 700*500 | 800*895 | 950*800 | 1000*800 | 1190*800 |
Shelf Quantity (Layer) | 5+1 | 6+1 | 7+1 | 8+1 | 10+1 | 11+1 |
Shelf Temperature (℃) | -60 to +70 | |||||
Water Catcher Temper (℃) | -65±5 | |||||
Max Catch Water（Kg） | 15 | 30 | 75 | 90 | 120 | 150 |
Ultimate Vacuum | 1 | 1 | 1 | 2 | 2 | 2 |
Electricity（kW） | 12 | 16 | 22 | 34 | 34 | 41 |
Size（Mm） | 2200*1000*2000 | 2500*1000*2300 | 2200*1200*2400 | 3500*1400*2430 | 3500*1400*2430 | 4540*1400*2450 |
Weight（Kg） | 1500 | 2000 | 2500 | 3000 | 3500 | 3800 |
Pre-sale:
* As soon as we get your inquiry, we will always reply to your email on time and try our best to recommend you the most suitable freeze dryer. Detailed tech info will also be provided for you.
* We can do sample tests for customers.
After-sale:
* If possible, please do come to our factory and we will teach workers the whole process of freeze-drying. The most appropriate time needed for freeze-drying will be tested by us.
* We will keep in touch with you, to make sure every part of the freeze dryer works well. One-year warranty, free online service for abroad customers.
