CE Certified Vegetables Fruit Freeze Dryer
CE Certified Vegetables Fruit Freeze Dryer
Product Description
Freeze-dry (brief named Freeze-dry) is a stable process of material dried which will put the material contained with water to freeze to solid first, then make among them of the water sublimate from solid to air condition, removing water to preserve materials
Products at solution stage are frozen through sublimation and desorption, then the solvent reduce to a certain extent, thereby preventing the formation of micro-organisms or chemical reaction between the solute and solvent that products can be preserved for a long time and maintained its nature.
Vacuum freeze-drying method is a liquid → solid → gaseous process. In freeze-drying process, "liquid bridge" between the solution particles has been frozen into "solid bridge". The relative position of particles has been fixed and does not exist surface tension on gas-liquid interface between the two particles. With the continuous distillation of solvent, "solid bridge" continuously decrease, but the the relative position between two particles will not longer change until the "solid bridge" completely disappear.
Technical Parameters
| Model | KFD-1 |
| Power | 167Kw, 380V±10%,50HZ,3Phase,5Wire |
| Shelf area | 41.86 |
| Water catching capacity | 800L |
| Shelf quantity | 14+1 |
| Compressed air | ≥40L/min（P=0.5~0.8Mpa） |
| Cooling water Quantity | ≥50m3/h（T≤30℃、P=0.2-0.3Mpa） |
| Defrost water Quantity | ≥4000kg（T≥30℃、P=0.1-0.2Mpa） |
| Whole volume(L×W×H) | 8000×3200×4600（mm） |
| Structure | Split |
| Total weight | 30T（Approx.） |
Technical Features
| 1 | The JAPAN ULVAC vacuum pump has been stable operation ensure |
| 2 | Vacuum pump check valve of high performance and vacuum pump can avoid backing due to the difference of atmospheric when pump stops |
| 3 | Multi-stage vacuum setting function, you can achieve a degree of vacuum freeze-drying cycle to control of multiple variables |
| 4 | Vacuum pump connected to the chamber isolated by electric vacuum solenoid valve he pump features an automatic isolating valve to hold the chamber pressure in the event of power failure or vacuum valve not reach as set point. |
Final Product
