Ginseng Freeze Drying Machine

If the ginseng freeze drying machine caters to your requirement, welcome to buy the precise equipment made in China from our factory. We are one of the professional manufacturers and suppliers in China who can offer you unmatched services and prices. And the customized service is also available. Don't hesitate any more.



Ginseng freeze drying machine

Ginseng is a perennial herbaceous plant, fleshy roots for strong tonic, applicable to adjust blood pressure, heart function recovery, and neurasthenia and frail, modern medicine thinks, ginseng on the nervous system, cardiovascular system, endocrine system, digestive system, respiratory system, reproductive system and the use of surgeons have obvious effect, such as It has the effect of expectorant, stomach, diuresis and excitement. The stems, leaves, flowers, fruits and by-products of ginseng are raw materials for light industry, which can be used to produce tobacco, wine, tea, crystal, paste and other commodities containing ginseng.

Traditional ginseng processing is basically by sun-drying, drying, microwave or infrared ray, etc. Traditional drying is prone to oxidation and variation, color change, shape shrinkage deformation, and high hardness after drying is inconvenient to take. And because of high temperature will destroy a variety of ginsenosides, amino acids and other nutrients. Modern freeze drying technology develops rapidly. Ginseng freeze drying machine is a low temperature freeze vacuum drying equipment independently developed by the freeze drying mechanism manufacturing factory. It is a freeze drying machine for Chinese medicinal materials and conforms to the GMP production standard. 1) Human participation in pre-freezing: after cleaning and processing the fresh ginseng, it is put into the lyophilized machine and frozen at -50℃ for 3-5 hours; 2) Pre-vacuuming: after fully pre-freezing, pre-vacuuming for 60min, the vacuum is maintained at about 20Pa; 3) Primary drying: after the pre-vacuum is finished, the primary drying stage is entered. At this stage, 90% of the solid ice in the ginseng is sublimated into gas under the control of the temperature and vacuum of the material by the lyophilizer within the technical range. The process ensures that the ginseng will not be deformed, discolored or destroyed nutrients. 4) Analytical drying: after most of the dried-water drying is completed, there is still a small part of bound water. The bound water has strong adsorption. It needs to be controlled by the curve temperature of FZG lyophilizer and kept in a vacuum environment of 5~ 30Pa to get the dried lyophilized ginseng with 3% water content.

Parameter:

Model	KFD-20	KFD-25	KFD-30
Tray area(m²)	20	25	30
Input capacity(kg/batch)	200	250	300
Min. cold trap temperature(℃)	<-45℃	<-45℃	<-45℃
Vacuum degree(pa)	<10pa	<10pa	<10pa
Tray temp.	-35~+100℃	-35~+100℃	-35~+100℃
Tray quantity	18	22	18
Tray Size(mm)	2200x600	2200x600	3300x600
Cooling method	Water cooled	Water cooled	Water cooled
Total power(kw)	45	50	60
Total weight(kg)	8000	9000	11000

Pre-sale:

As soon as we get your inquiry, we will always reply to your email on time and try our best to recommend you the most suitable freeze dryer. Detailed tech-info will also be provided for you.

After-sale:

We will keep in touch with you, to make sure every parts of the freeze dryer work well. One year warranty, free online service.
