Composition Of Lyophilizer

Lyophilizer which is mainly composed of the following components: Compressor, refrigerant, condenser, oil separator, filter drier, intercooler, depending on the liquid mirror, solenoid valve, hand valve (top), expansion valve, evaporator, plate exchanger, box after condensing coil), gas-liquid separator, gas filters, pressure gauges, pressure control relay, CPCE (energy regulator), relief valve, cooling pipe, etc. The working principle of the refrigeration system is to form a closed system by connecting the pipes between these components. The refrigerant circulates constantly in the system, changes its state and exchanges heat with compressed air and cooling medium.

The refrigerating compressor of the lyophilizer inhales the low-pressure (low-temperature) refrigerant in the evaporator into the cylinder of the compressor. The refrigerant vapor is compressed, and the pressure and temperature rise at the same time. The refrigerant steam at high pressure and high temperature is pressed to the condenser. In the condenser, the refrigerant steam at a higher temperature exchanges heat with the cooling water or air at a lower temperature. The heat of the refrigerant is taken away by water or air and condensed down, and the refrigerant steam becomes liquid. This part of the liquid is then transported to the expansion valve, through the expansion valve throttle into low temperature and low pressure liquid and into the evaporator; In the evaporator, the low temperature and low pressure refrigerant liquid absorbs the heat of the compressed air and vaporizes (commonly known as "evaporation"), and the compressed air is cooled and condenses a large amount of liquid water; The refrigerant steam in the evaporator is sucked away by the compressor, so that the refrigerant in the system through compression, condensation, throttling, evaporation such four processes, so as to complete a cycle.

In the freeze-drying mechanism cooling system, the evaporator is the equipment to transport the cold amount, in which the refrigerant absorbs the heat of the compressed air and realizes the purpose of dehydration and drying. The compressor is the heart, which inhales, compresses and transports refrigerant vapor. The condenser is the equipment that releases heat. The heat absorbed in the evaporator is transferred to the cooling medium (such as water or air) together with the heat converted from the input power of the compressor. The expansion valve/throttle valve has the function of throttling and depressing the refrigerant, controlling and regulating the quantity of refrigerant liquid flowing into the evaporator at the same time, and dividing the system into two parts: high pressure side and low pressure side.

Parameter:

Pre-sale:

As soon as we get your inquiry, we will always reply to your email on time and try our best to recommend you the most suitable freeze dryer. Detailed tech-info will also be provided for you.

After-sale:

We will keep in touch with you, to make sure every parts of the freeze dryer work well. One year warranty, free online service.
