Freeze dryers are our major products, the size of freeze dryers varies from 0.5 to 200m². Any detailed parameters can be customized until it meets customers’ requirements. Our product has one year warranty, and our team has years of experience in this freeze drying field.

Send Inquiry

Chat Now

Product Introduction

Freeze drying mask machine

Lyophilized powder mask, referred to as lyophilized mask, is a lyophilized solid original solution mask. The original solution, thickener, moisturizer and other components of the mask are fused with the fiber of the membrane cloth, and then SFD vacuum freeze-drying technology is used to sublimate the water after fusion to form a solid dry film mask. The lyophilized mask has the advantages of maintaining nutrition, easy to store and easy to use.

blob

freeze drying mask production equipment: mask machine - sterilizing and sterilizing machine - elevator - weighing, lifting and removing machine - counting, turning and pushing material - collecting box - weighing and kicking machine - edge sealing machine - shrinking furnace - freeze drying machine - sorting and counting machine - packing machine - coding machine.

freeze-dried mask process: liquid mixing - homogenizing - making face type film cloth - disinfection and sterilization - mask filling - freeze drying - sorting and counting - packing and coding.

The whole project freeze-dried mask freeze-drying production line needs freeze-drying technology and equipment, and the production and processing can be carried out according to the process of freeze-dried mask. For specific plans, you can ask freeze-drying mechanism manufacturing factory for consultation, and provide production equipment, process design and installation training support services.

Parameter:

Model	KFD-20	KFD-25	KFD-30	KFD-50	KFD-100
Tray area(m²)	20	25	30	50	100
Input capacity(kg/batch)	200	250	300	500	1000
Min. cold trap temperature(℃)	<-45℃	<-45℃	<-45℃	<-45℃	<-45℃
Vacuum degree(pa)	<10pa	<10pa	<10pa	<10pa	<10pa
Tray temp.	-35~+100℃	-35~+100℃	-35~+100℃	-35~+100℃	-35~+100℃
Tray quantity	18	22	18	28	36
Tray Size(mm)	2200x600	2200x600	3300x600	3300x600	5000x600
Cooling method	Water cooled	Water cooled	Water cooled	Water cooled	Water cooled
Total power(kw)	45	50	60	100	180
Total weight(kg)	8000	9000	11000	20000	40000
