Pharmaceutical Lyophilizer For Serum Vaccine Reagent Storage
Input capacity:From 500 to 1500kg
Warranty:One year
Highlights:Can be customized
Pharmaceutical Lyophilizer For Serum Vaccine Reagent Storage
Features
1)Pre-freeze drying in situ, to reduce the tedious operation of the drying process to achieve the freeze-drying process automation
2)Silicone oil as a circulating medium, temperature control accuracy, shelf temperature ≤ 1 ℃, the drying effect is even
3)Shelf pitch design available shelf spacing variable function to facilitate large difference in height lyophilized product.
4)A variety of extensions - eutectic point measurement, computer remote control, dew point measurement functions
Parameters
|
Model |
KFD-50 |
KFD-100 |
KFD-150 |
|
Capacity (Kg/Batch) |
500 |
1000 |
1500 |
|
Shelf Area (㎡) |
52 |
102 |
152 |
|
Shelf Size (Mm) |
3300*600 |
5000*600 |
10000*600 |
|
Shelf Quantity (Layer) |
13+1 |
17+1 |
13+1 |
|
Shelf Quantity (Piece) |
28 |
36 |
28 |
|
Space Between(Mm) |
95 | ||
|
Shelf Temperature (℃) |
room to 120 | ||
|
Water Catcher Temper (℃) |
-65±5 | ||
|
Max Catch Water(Kg) |
750 |
1500 |
2200 |
|
Ultimate Vacuum (Pa) |
5 | ||
|
Electricity(Kw) |
168 |
232 |
287 |
|
Weight(Kg) |
12500 |
20000 |
40000 |
Main features and functions
1. Freeze drying process
Pre-freezing: First freeze the serum, vaccine or reagent to an extremely low temperature (usually -40°C to -80°C) to ensure that the water in the sample is completely frozen.
Sublimation: Under vacuum conditions, the frozen water is directly converted from solid to gas (sublimation) without passing through the liquid state. This step requires precise vacuum and temperature control to protect the active substance from thermal damage.
Secondary drying: After sublimation is completed, the sample is further heated to remove residual water and reduce the moisture content of the sample to between 1% and 4% to ensure long-term stable storage.
2. Vacuum system
The pharmaceutical freeze dryer uses an efficient vacuum pump to maintain a low-pressure environment in the chamber to ensure that the water can be effectively removed by sublimation. The vacuum system needs to be highly stable to prevent the sample from being contaminated by the external environment.
3. Aseptic design
The freeze dryer must ensure a sterile environment in the chamber to prevent the serum, vaccine and reagent from being invaded by microorganisms or other contaminants during processing. It is usually equipped with a HEPA filtration system to ensure that the air quality meets pharmaceutical grade sterility requirements.
The closed system design ensures that no external pollution sources are introduced during the entire operation process.
Our Service
Pre-Sales Service
* Fast response speed,all inquiry will be replied in 5mins during working time,and max 1h off working,.
* Professional sale guidance to make sure we recommend you most suitable one to save cost according to your needs!
* Whole technical team offer service for any question.
*10 years experience of exporting from selling to transporting
After-Sales Service
* 1 years quality warranty,
* Professional technical team offer technical guidance,
* Welcome to visit our factory anytime!
Honor We Own
why choose us
Kassel Machinery (Zhejiang) Co., Ltd. has always kept pace with the times and has always been at the forefront of technology and market. With its excellent operating performance, minimal energy consumption and other advantages of producing high-quality products, it has quickly seized the market. The products are not only selling well domestically market, and also exported to foreign markets.
With its strong technical background and rich customer service experience as its core, Kassel is committed to providing customers with high-quality machinery at favorable prices. The product has stable performance, high precision, safety and durability, which can help customers improve product yield, reduce production costs, and improve market competitiveness.
