1000kg Industrial Pharmaceutical Freeze Dryer Lyophilizer
1000kg Industrial Pharmaceutical Freeze Dryer Lyophilizer
Features
1.Standard products products temperature ≤-55 ℃ cold trap temperature ≤-75 ℃ vacuum degree ≤1Pa.
2.Modular product by system configuration, modular manufacturing, maintenance and more professional.
3.The end discriminant function at the end of secondary drying, the program automatically enters end discrimination in the confirmation dried products, prompted to enter the next step.
4.Sterile isolation design reliable machine or sterile isolation placement, user-friendly multi-site use.
5.The whole process of vacuum control provide the degree of vacuum drying phase variable control, automated operation.
Parameters
Model | K-100 |
Capacity (Kg/Batch) | 1000 |
Shelf Area (㎡) | 102 |
Shelf Size (Mm) | 5000*600 |
Shelf Quantity (Layer) | 17+1 |
Shelf Quantity (Piece) | 36 |
Space Between（Mm） | 95 |
Shelf Temperature (℃) | room to 120 |
Water Catcher Temper (℃) | -65±5 |
Max Catch Water（Kg） | 1500 |
Ultimate Vacuum （Pa） | 5 |
Electricity（Kw） | 232 |
Weight（Kg） | 20000 |
Application
a. Live bacteria vaccine. For example, BCG vaccine, meningococcal vaccine, tuberculosis vaccine, oral live dysentery vaccine, salmonella, streptococcus, etc.
b. Fire vaccine. For example, measles vaccine, flu vaccine, rabies vaccine, chicken plague vaccine, etc.
c. Other biological products, biochemical drugs. Hepatitis B surface antigen diagnosis snowball, human leukocyte interferon, coenzyme A (CoA), adenosine triphosphate (ATP), urokinase, etc.
FAQ
Q1：Are you a manufactuer or trading company?
A:We are the manufacturer with decades of research and development production experience.
Q2:Packaging & Shipping:
A:Export Wooden case&FOB Shanghai
Q3:What's the MOQ for your production?
A:One set.
Q4:What's your payment term?
A:50% T/T prepay,50% when you see the copy of B/L.
Q5:How long is the warranty period?
A:The warranty period is 12 months.
