Lab Use Freeze Dryer

If the lab use freeze dryer caters to your requirement, welcome to buy the precise equipment made in China from our factory. We are one of the professional manufacturers and suppliers in China who can offer you unmatched services and prices. And the customized service is also available. Don't hesitate any more.



Lab Use Freeze Dryer

The performance indexes pursued by the Lab use freeze dryer are small volume, light weight, multiple functions, stable performance and high accuracy of the test system. It is suggested that one machine can be used for multiple purposes and can adapt to the freeze-drying experiment of various materials. The main classification methods of the types of freeze dryers in the experimental series are as follows:

1. Structurally

Bell jar type freeze dryer: the freeze-drying chamber and cold trap are separate upper and lower structures, and the freeze-drying chamber has no pre freezing function. This type of lyophilizer needs manual operation when it is transferred to the drying process after the pre freezing of materials. Most of the experimental lyophilizers are bell jar type, which has the advantages of simple structure and low cost. Most of the freeze-drying chambers use transparent plexiglass cover, which is convenient to observe the freeze-drying of materials.

In situ freeze dryer: the freeze-drying chamber and the cold trap are two independent chambers. The shelf in the freeze-drying chamber has refrigeration function. After the materials are placed in the freeze-drying chamber, there is no need for manual operation in the pre freezing and drying process of the materials. The manufacturing process of this type of lyophilizer is complex and the manufacturing cost is high, but the in-situ lyophilizer is the development direction of the lyophilizer and an ideal choice for exploring the lyophilization process. It is especially suitable for the lyophilization of medicine, biological products and other special products.

2. From the functional point of view

Ordinary shelf type: the materials are stored in bulk in the material tray, which is suitable for the freeze-drying of food, Chinese herbal medicine and powder materials.

Type with capping device: it is suitable for the drying of Xilin bottled materials. During freeze-drying preparation, the materials are sub packed into Xilin bottles as required. After floating the bottle cap, freeze-drying is carried out. After drying, the capping mechanism is operated to press the bottle cap, which can avoid secondary pollution and re adsorb water, and is easy for long-term storage.

Multi manifold type: the flask is connected outside the drying chamber to dry the materials spun frozen on the inner wall of the flask. At this time, the flask is connected to the manifold outside the drying oven as a container. The materials in the flask are heated at room temperature. Through the multi manifold switch device, the flask can be removed or installed at any time as required without shutdown.

With pre freezing function: in the process of material pre freezing, the cold trap is used as the pre freezing chamber to pre freeze the material. In the drying process, the cold trap is used as a water trap to capture the overflow water of the material. For the freeze dryer with pre freezing function, the pre freezing and drying of materials in the freeze-drying process are completed on the freeze dryer. The use efficiency of the freeze dryer is high and the cost of low-temperature refrigerator is saved.

Parameter:

Model	KFD-20	KFD-25	KFD-30	KFD-40	KFD-50	KFD-100	KFD-150	KFD-200
Capacity (Kg/Batch)	200	250	300	400	500	1000	1500	2000
Shelf Area (㎡)	20	25	400	40	52	102	152	201
Shelf Size (Mm)	2200*600	2200*600	3300*600	3300*600	3300*600	5000*600	10000*600	9900*600
Shelf Quantity (Layer)	8+1	10+1	8+1	10+1	13+1	17+1	13+1	17+1
Shelf Quantity (Piece)	18	22	18	18	28	36	28	36
Space Between（Mm）	95
Shelf Temperature (℃)	room to 120
Water Catcher Temper (℃)	-65±5
Max Catch Water（Kg）	300	380	450	600	750	1500	2200	3000
Ultimate Vacuum （Pa）	5
Electricity（Kw）	63	72	101	116	168	232	287	384

Pre-sale:

* As soon as we get your inquiry, we will always reply to your email on time and try our best to recommend you the most suitable freeze dryer. Detailed tech-info will also be provided for you.

* We can do sample test for customers.

After-sale:

* If possible, please do come to our factory and we will teach workers the whole process of freeze drying. The most appropriate time needed for freeze drying will be tested by us.

* We will keep in touch with you, to make sure every parts of the freeze dryer work well. One year warranty, free online service for abroad customers.
